DIY Home Improvement, Remodeling & Repair Forum > DIY Home Improvement > Plumbing Forum > why is water coming out of the showerhead and handheld shower at the same time.




Reply

Thread Tools Search this Thread Display Modes
Old 03-26-2014, 10:47 AM
sisyphus
Senior Member

Join Date: Apr 2011
Location: orange county, ny
Posts: 129
Default why is water coming out of the showerhead and handheld shower at the same time.

hello all, installed a new shower fixture and a handheld shower on what would normally be where the tub spout would go. I also installed one of those small shut off valve that you normally put on your shower arm where I have the handheld shower. when I turn the shower on, I get water coming out of the showerhead and the handheld shower at the same time. can someone give me any advce as to what I messed up? thanks



__________________
sisyphus is offline

Reply With Quote Quick reply to this message
Old 03-26-2014, 03:09 PM
Wuzzat?
Banned

Join Date: Jan 2010
Posts: 2,328
Liked 167 Times on 154 Posts
Likes Given: 94

Default

There's a valve that is held open by gravity or water pressure and diverts the water to the spout
except
when the pressure drops because you opened the valve to the handheld unit and then all the water is supposed to come out of the handheld unit?



__________________
Wuzzat? is offline

Reply With Quote Quick reply to this message
Old 03-26-2014, 06:48 PM
nealtw
Contractor

Join Date: Nov 2010
Location: vancouver, b.c.
Posts: 10,976
Liked 963 Times on 856 Posts
Likes Given: 1648

Default

Your deverter valve is leaking. You have a flow resticter im the shower head that build up pressure and it leaks thru the deverter valve. Most people just put the valve at the shower head and have them both up top, and they leak there too.

__________________
nealtw is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 08:03 AM
guyod
Senior Member

Join Date: Jan 2008
Location: Wind Gap, PA
Posts: 423
Liked 21 Times on 20 Posts
Likes Given: 8

Default

Im not sure what you are using for a shut off valve but it obviously isn't working. Try a different shut off valve.
Use something like this

__________________
guyod is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 09:26 AM
sisyphus
Senior Member

Join Date: Apr 2011
Location: orange county, ny
Posts: 129
Default

here's a couple of pictures of the shut off valves I've tried including the laundry bib I've tried last. the laundry bib seems to lessen the amount of water coming out of the showerhead when I open it completely. but there's still quite a bit of water coming out of the shower head. simular to a weak shower. thanks for the responses.

__________________

Last edited by sisyphus; 03-28-2014 at 09:29 AM.
sisyphus is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 11:05 AM
nealtw
Contractor

Join Date: Nov 2010
Location: vancouver, b.c.
Posts: 10,976
Liked 963 Times on 856 Posts
Likes Given: 1648

Default

Water finds the easiest route to travel, any restiction on the water will build up pressure, it dosn't take much to drive the water to the shower head. On a reguler tub spout the pipe in the spout is larger to deal with this problem. You are going to find a way to put a valve to turn off the flow to the shower head.

__________________
nealtw is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 12:44 PM
nealtw
Contractor

Join Date: Nov 2010
Location: vancouver, b.c.
Posts: 10,976
Liked 963 Times on 856 Posts
Likes Given: 1648

Default

This is a bit pricy but something like this is what is needed.
http://www.tsbrass.com/products/b-10...diverter-valve

__________________
nealtw is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 02:24 PM
sisyphus
Senior Member

Join Date: Apr 2011
Location: orange county, ny
Posts: 129
Default

thanks for the suggestion, including the shut off valve. however if I have to open the wall up my wife's going to kill me. this project took longer than expected. I'll have to live with it, or figure something else. thanks again.

__________________
sisyphus is offline

Reply With Quote Quick reply to this message
Old 03-28-2014, 02:52 PM
nealtw
Contractor

Join Date: Nov 2010
Location: vancouver, b.c.
Posts: 10,976
Liked 963 Times on 856 Posts
Likes Given: 1648

Default

Can you get to the pipe going to the shower anywhere esle like thru some drywall in another room, then you could just drill a single hole thru the tile, maybe. Just a single shut off valve would work.

__________________
nealtw is offline

Reply With Quote Quick reply to this message
Old 03-29-2014, 03:59 PM
sisyphus
Senior Member

Join Date: Apr 2011
Location: orange county, ny
Posts: 129
Default

let me think about this. thanks again



__________________
sisyphus is offline

Reply With Quote Quick reply to this message
